Every operation and application is different. That’s why W.S. Tyler customizes T-Class circular vibrating aggregate screens to your material and production needs. Heavy-duty W.S. Tyler vibrating screens have been counted on by aggregate producers for more than 50 years to precisely classify material into valuable product. Some basic options for the modular T-Class include: - Single or double shaft configuration to meet higher capacity and coarse applications
- Precisely screens material from 6 inches down to 20 mesh
- Available in sizes from 4 ft. x 8 ft. up to 8 ft. x 24 ft.
- Choose up to 4-1/2 screen decks
- Available with inclines between 10 and 25 degrees
 The T-Class can be easily customized to fit your application | |  The T-Class is backed by a standard 18-month warranty | | Customizing A Vibrating Screen To Your Standards
Much like premium automobiles, W.S. Tyler T-Class vibrating screens are built on platforms that combine a machine width and one of W.S. Tyler’s concentric shaft drive types with bearing sizes ranging from 120 mm to 160 mm. Within a platform, the customer chooses basic parameters, such as screen length and the amount of decks his application requires. Within the self-set parameters, the customer can choose between multiple variables, such as deck setup, feed and discharge arrangements, suspension systems, reinforcement plates, wear lining and stroke and speed combinations. In addition, T-Class vibrating screens allow for the use of multiple screen media types on each deck to meet your screening requirements.  The T-Class’ heavy-duty body design has minimal welds to avoid fatigue cracking | | | T-Class Strengthens Your Operation
T-Class vibrating screens are built to withstand the most rugged application challenges, ensuring the producer’s process reliability and longevity. Its features include: - Heavy-duty body design with minimal welds to avoid fatigue cracking
- 90-degree top and 45-degree bottom Durabend side plates for higher body rigidity
- Hands-free tube housing allows for bearing work without come-alongs or drift pins
- Patented angle box tensioning system for properly tensioned screen media
These standard features are complimented by a list of options, such as: - Dust enclosures to ensure a safe and clean working environment
- Auto-lube systems to simplify maintenance efforts
- Constant bearing life and temperature monitoring systems to avoid unscheduled down time
- Ty-Rider mounting system to eliminate lateral screen movement and reduce noise pollution
The T-Class is backed by a standard 18-month warranty from date of shipment, which can be increased according to customer-specific warranty upgrade packages. Every Screen Ships Ready To Work
Before a T-Class vibrating screen is shipped, W.S. Tyler performs a thorough Vibration Analysis. This test assures proper workmanship and that the screen is built to W.S. Tyler quality standards, while correctly balanced and smoothly operating, adhering to acceptable noise levels. Once on-site, W.S. Tyler tests the screen again during commissioning to make sure optimal performance is achieved within the customer’s operation and structure. To learn more about W.S. Tyler T-Class vibrating screens, go to the REQUEST MORE INFO button above or click on the DIRECT CONTACT button to reach W.S. Tyler directly.
|
